Alternator 28V 55A, Components: 845940
|
1. |
Alternator (873757)
Price: $0.00SUGGESTED QTY:1
For 24 voltage ...
VIEW DETAILS
|
|
|
2. |
Rotor (847704)
Price: $99,999.00SUGGESTED QTY:1
Obsolete part
VIEW DETAILS
|
|
|
3. |
Stator (864346)
Price: $99,999.00SUGGESTED QTY:1
VIEW DETAILS
|
|
|
4. |
Nut set (847706)
Price: $66.10SUGGESTED QTY:1
VIEW DETAILS
|
|
|
6. |
End plate (3828407)
Price: $99,999.00SUGGESTED QTY:1
Obsolete part
VIEW DETAILS
|
|
|
7. |
Ball bearing (847708)
Price: $303.00SUGGESTED QTY:1
VIEW DETAILS
|
|
|
8. |
Housing (3807905)
Price: $2,070.00SUGGESTED QTY:1
VIEW DETAILS
|
|
|
9. |
Bearing carrier (847709)
Price: $23.10SUGGESTED QTY:1
VIEW DETAILS
|
|
|
10. |
Screw kit (847710)
Price: $60.69SUGGESTED QTY:1
VIEW DETAILS
|
|
|
11. |
Diode bridge (1698689)
Price: $99,999.00SUGGESTED QTY:1
This diode brid...
VIEW DETAILS
|
|
|
12. |
Bearing race (840629)
Price: $99,999.00SUGGESTED QTY:1
Obsolete part
VIEW DETAILS
|
|
|
13. |
Ball bearing (840630)
Price: $99,999.00SUGGESTED QTY:1
Obsolete part
VIEW DETAILS
|
|
|
14. |
Protecting casing (847712)
Price: $15.10SUGGESTED QTY:1
VIEW DETAILS
|
|
|
15. |
Regulator kit, with brush holder (872368)
Price: $318.00SUGGESTED QTY:1
(864006)
VIEW DETAILS
|
|
|
16. |
Screw (859312)
Price: $5.50SUGGESTED QTY:6
VIEW DETAILS
|
|
|
17. |
Brush retainer (840632)
Price: $120.00SUGGESTED QTY:1
VIEW DETAILS
|
|
|
18. |
Screw (859312)
Price: $5.50SUGGESTED QTY:6
VIEW DETAILS
|
|
|
19. |
Hexagon nut (955779)
Price: $1.00SUGGESTED QTY:1
M4, w
VIEW DETAILS
|
|
|
19. |
Flange nut (965483)
Price: $0.30SUGGESTED QTY:2
M5, D+, B-
VIEW DETAILS
|
|
|
19. |
Flange nut (945407)
Price: $0.60SUGGESTED QTY:1
VIEW DETAILS
|
|
|
20. |
Spring washer (941904)
Price: $0.10SUGGESTED QTY:1
W
VIEW DETAILS
|
|
|
21. |
Guide (840634)
Price: $23.50SUGGESTED QTY:1
VIEW DETAILS
|
22 Items
