Reverse Gear HS63IV-A


1.	Housing (3582221) This product has been discontinued Price: $99,999.00 SUGGESTED QTY:1 Obsolete part VIEW DETAILS
2.	Reverse Gear HS63IV-A, Components: Ratio 2.48:1 (36670) This product has been discontinued Price: $0.00 SUGGESTED QTY:1 VIEW DETAILS
2.	Transmission housing (40005873) Price: $1,445.00 SUGGESTED QTY:1 VIEW DETAILS
2.	Reverse Gear HS63IV-A, Components: Ratio 1.56:1 (36666) This product has been discontinued Price: $0.00 SUGGESTED QTY:1 VIEW DETAILS
2.	Reverse Gear HS63IV-A, Components: Ratio 1.99:1 (36669) This product has been discontinued Price: $0.00 SUGGESTED QTY:1 VIEW DETAILS
3.	Dowel (3582045) Price: $26.50 SUGGESTED QTY:2 VIEW DETAILS
4.	Hexagon screw (970949) Price: $3.30 SUGGESTED QTY:10 VIEW DETAILS
5.	Hexagon screw (970948) Price: $1.10 SUGGESTED QTY:2 VIEW DETAILS
6.	Flange screw (947790) Price: $4.30 SUGGESTED QTY:4 VIEW DETAILS
7.	Spring washer (941908) Price: $0.40 SUGGESTED QTY:10 VIEW DETAILS
8.	Sealing (3582047) Price: $142.00 SUGGESTED QTY:1 VIEW DETAILS
9.	Sealing ring (40005871) Price: $180.00 SUGGESTED QTY:1 Ratio 1.56:1 VIEW DETAILS
9.	Sealing ring (3582229) Price: $288.00 SUGGESTED QTY:1 Ratio 1.99:1, 2... VIEW DETAILS
10.	Plug (968146) Price: $5.30 SUGGESTED QTY:1 VIEW DETAILS
11.	Dipstick (3582224) Price: $146.00 SUGGESTED QTY:1 VIEW DETAILS
12.	O-ring (3582203) Price: $5.60 SUGGESTED QTY:1 VIEW DETAILS
13.	Filter cap (3582063) Price: $403.00 SUGGESTED QTY:1 VIEW DETAILS
14.	Hexagon screw (940142) Price: $1.50 SUGGESTED QTY:1 VIEW DETAILS
15.	Washer (976944) Price: $0.10 SUGGESTED QTY:1 VIEW DETAILS
16.	Cover (244678) This product has been discontinued Price: $99,999.00 SUGGESTED QTY:1 Obsolete part VIEW DETAILS
17.	O-ring (3582065) Price: $15.60 SUGGESTED QTY:1 VIEW DETAILS
18.	O-ring (3582064) Price: $7.80 SUGGESTED QTY:1 VIEW DETAILS
19.	Oil filter (3582069) Price: $92.50 SUGGESTED QTY:1 VIEW DETAILS
20.	O-ring (3582065) Price: $15.60 SUGGESTED QTY:1 VIEW DETAILS
21.	O-ring (3582064) Price: $7.80 SUGGESTED QTY:1 VIEW DETAILS
22.	Oil filter (21707132) Price: $30.80 SUGGESTED QTY:1 VIEW DETAILS
23.	Sealing (3582049) Price: $17.10 SUGGESTED QTY:1 VIEW DETAILS
24.	Valve (3582050) Price: $76.30 SUGGESTED QTY:1 VIEW DETAILS
24.	Breather cap (3582050) Price: $76.30 SUGGESTED QTY:1 Ratio 1.56:1 VIEW DETAILS
25.	Plug (3581973) Price: $10.40 SUGGESTED QTY:1 VIEW DETAILS
26.	Gear selector valve (21116465) Price: $1,844.00 SUGGESTED QTY:1 VIEW DETAILS
27.	Gasket (3582046) Price: $46.30 SUGGESTED QTY:1 VIEW DETAILS
28.	Spring washer (941907) Price: $0.70 SUGGESTED QTY:6 VIEW DETAILS
29.	Hex. socket screw (941761) Price: $2.70 SUGGESTED QTY:6 VIEW DETAILS
30.	Engagement lever kit (21228853) Price: $209.00 SUGGESTED QTY:1 VIEW DETAILS
31.	Lever fork (21228853) Price: $209.00 SUGGESTED QTY:1 VIEW DETAILS
32.	Spring washer (941908) Price: $0.40 SUGGESTED QTY:10 VIEW DETAILS
33.	Hexagon screw (955298) Price: $2.40 SUGGESTED QTY:1 VIEW DETAILS
34.	Hexagon nut (955782) Price: $1.10 SUGGESTED QTY:1 VIEW DETAILS

39 Items

Grouped product items
Product Name	Qty
Housing $99,999.00
Reverse Gear HS63IV-A, Components: Ratio 2.48:1 Starting at $1.70
Transmission housing $1,445.00
Reverse Gear HS63IV-A, Components: Ratio 1.56:1 Starting at $1.70
Reverse Gear HS63IV-A, Components: Ratio 1.99:1 Starting at $1.70
Dowel $26.50
Hexagon screw $3.30
Hexagon screw $1.10
Flange screw $4.30
Sealing $142.00
Sealing ring $180.00
Sealing ring $288.00
Plug $5.30
Dipstick $146.00
O-ring $5.60
Filter cap $403.00
Hexagon screw $1.50
Washer $0.10
Cover $99,999.00
Oil filter $92.50
O-ring $15.60
O-ring $7.80
Oil filter $30.80
Sealing $17.10
Breather cap $76.30
Valve $76.30
Plug $10.40
Gear selector valve $1,844.00
Gasket $46.30
Spring washer $0.70
Hex. socket screw $2.70
Engagement lever kit $209.00
Lever fork $209.00
Spring washer $0.40
Hexagon screw $2.40
Hexagon nut $1.10
